Ratchet Lever Block
Ratchet Lever Block Details
LIFTONOMICS Ratchet lever hoist can be supplied from 0. 5 ton cap to 6 ton capacity.
LIFTONOMICS Ratchet lever hoist are being supplied to various crane preparers and also to various engineering industries.
Heavy duty cranes require such lever hoist for picking, loading and adjusting a variety of containers, concrete blocks and iron spat. Clients find our lever hoist, LIFTONOMICS, dimensionally accurate and aligned when used for heavy operations.
Model | 0.75 Ton | 1 Ton | 1.5 Ton | 3 Ton | 6 Ton | 9 Ton | |
Rated Lifting Weight (T) | 0.75 | 1 | 1.5 | 3 | 6 | 9 | |
Standard Lifting height (MTR) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
Testing Load (T) | 11 | 15 | 23 | 37.5 | 75 | 135 | |
Lifting Chain lines | 1 | 1 | 1 | 1 | 2 | 3 | |
Strands of Load Chain (mm) | 6 | 6 | 7 | 10 | 10 | 10 | |
Dimensions | A | 148 | 148 | 172 | 200 | 200 | 200 |
B | 90 | 90 | 98 | 115 | 115 | 115 | |
C | 136 | 136 | 160 | 180 | 235 | 330 | |
D | 40 | 40 | 44 | 50 | 64 | 85 | |
H | 320 | 320 | 380 | 480 | 600 | 700 | |
L | 280 | 280 | 410 | 410 | 410 | 410 | |
K | 27 | 27 | 34 | 38 | 48 | 57 | |
Net Weight (kg) | 7 | 7 | 10 | 17.5 | 28.5 | 45 | |
Packing Measurement (L x W x H) | 37 x 16 x 15 | 37 x 16 x 15 | 51 x 17 x 15 | 52 x 20 x 18 | 54 x 20 x 20 | 56 x 32 x 23 |
